    HRY51-G/C LED Series Industrial Explosion Proof Lighting for Fluorescent Lamp T8 Tube IP66

    Ask Lasest Price
    Brand Name : Warom
    Model Number : HRY51-G/C LED
    Certification : IECEx; ATEX; CU-TR
    Payment Terms : T/T
    • Product Details
    • Company Profile

    HRY51-G/C LED Series Industrial Explosion Proof Lighting for Fluorescent Lamp T8 Tube IP66

    Product Introduction


    Specification
    Global (IECEx)IECEx CML 20.0167X
    Gas and dust

    Ex db eb IIC T□ Gb1);

    Ex db eb q IIC T□ Gb1);

    Ex tb IIIC T80℃ Db IP66/IP67

    Europe (ATEX)CML 20 ATEX 1296X
    Gas and dust

    II 2 G Ex db eb IIC T□ Gb1)

    II 2 G Ex db eb q IIC T□ Gb1)

    II 2 G Ex tb IIIC T80℃ Db IP66/IP67

    CertificatesIECEx; ATEX; CU-TR;INMETRO
    Conformity to standardsEN; IEC
    Degree of protectionIP66
    Ambient temperature


    -40℃~+57℃;-40℃~+58℃;-40℃~+53℃;-40℃~+48℃;



    Data
    MaterialStainless steel
    Weight4.3~8.1kg
    Lamp specificationLED tubes (supplied with the light fittings)
    Lamp power (W)

    T8:36W(18W) x 2;

    LED:18W(9W/14W/28W) x 2

    Rated voltage9Wx2, 18Wx2: 170~264V AC 50/60Hz
    14Wx2, 28Wx2: 100~277V AC 50/60Hz, 200~250V DC
    Rated luminous flux1850~6500lm
    Terminal3 x 1.5~4mm2 (L+N+PE)
    Cable entries4 x Φ21: 4 x M20 x 1.5 cable glands (DQM-I Ex e, plastic)
    Available cable outer diameterΦ9~Φ16 (mm)


    Download


    BAY51-G Series Explosion-proof Light Fittings for Fluorescent Lamp

    (Download here:icon_pdf.gifHRY51-G C LED Series Explosion-proof Light Fittings.pdf)


    Global (IECEx):IECEx CQM 19.0013X
    (Download here:(icon_pdf.gifIECEx CML 20.0167X Issue No.1.pdf)
