    HRT97 Series Explosion-proof LED Floodlights(Ex ec mc IIC)

    Ask Lasest Price
    Brand Name : WAROM
    Model Number : HTR97
    Certification : IECEx; ATEX;
    • Product Details
    • Company Profile

    HRT97 Series Explosion-proof LED Floodlights(Ex ec mc IIC)

    HRT97 Series Explosion-proof LED Floodlights(Ex ec mc IIC)

    Specification

    Global (IECEx)IECEx(applied for)
    Gas and dust

    Ex ec mc llC T4/T3 Gc
    Ex tb llIC T130℃/T195℃ Db

    Europe(ATEX)ATEX (applied for)
    Gas and dust

    II 3 G Ex ec mc IIC T4/T3 GC
    II 2 D Ex tb IIC T130℃/T195℃ Db

    CertificatesIECEx; ATEX;
    Conformity to standardsEN; IEC
    Degree of protectionIP66


    Data

    Material


    Enclosure:Copper-free Aluminium Alloy, powder coated surface,


    Glass cover:Polycarbonate,stands 4Jimpact


    LED driver:Wide voltage input, CC-CV (constant current - constant voltage) output, power factor 20.95with function of distributed current, constant current,surge-proof and anti-electromagneticinterference, and protection against overcurrent, open circuit, and short circuit.


    Exposed fastener:Stainless steel

    Lamp specificationLED module, Multiple LED
    Lamp power (W)200W, 400W, 600W,80OW, 1000W
    Colour temperature (CCT)

    5000K

    Note: nature white is available in general. Warm white is optional.
    please specify when ordering.

    Colour rendering index (Ra)≥80
    Ambient temperatureT4/T130℃for tamb:-60℃~+40℃
    T3/T195℃for tamb:-60℃~+60℃
    Emergency lighting time120/180 Mins
    Rated voltage100~277VAC 50/60Hz.150~250VDC
    Terminal3 x 1.5~4mm2 (L+N+PE)
    Cable entries1x M20 x1.5 cable gland (DQM-l Ex e)(M25 x 1.5 is optional)

    Download

    BnY81-LED Series Explosion-proof Light Fittings for Fluorescent Lamp

    (Download here:icon_pdf.gifHRT97 Series Explosion-proof LED Floodlights.pdf)
